Big-Grip Dead-ends are designed for use on Transmission, Antenna, Communications, and other types of guyed structures that require use of large guy strand.
For use on: Extra High Strength Siemens Martin High Strength Utilities Grade
Color Code: Black
Length: 64 Inch
Strand Size: 5/8"
Strand Construction 7W or 19W
Holding Straight 42,400 - 40,200

Big-Grip Dead-ends are designed for use on Transmission, Antenna, Communications, and other types of guyed structures that require use of large guy strand.
For use on: Extra High Strength Siemens Martin High Strength Utilities Grade
Color Code: Yellow
Length: 55 Inch
Strand Size: 9/16"
Strand Construction 7W or 19W
Holding Straight 35,000

H-J1512 Brace, Cross-arm, Span 72", Drop 22"
One piece, angle steel, double span braces are used to support heavy cross-arm construction. Braces are attached to the underside of the cross-arm with 1/2" bolts or lag screws and fastened to the pole with a 5/8" bolt. The pole mounting section is designed to allow more than ample clearance for wrenching.

H-4069 Crossover Clamp for 1/4" Strand

• Used in aerial construction at the mid-span to clamp two 1/4" strands together perpendicularly
• Crossover plates are tapped to eliminate the handling of loose nuts
• Stamped from AISI 1008 Steel

PLP GDE-1104LA 1/4" Dead-End Guy-Grip, Light Application - "A" Coat For use on mischmetal alloy
dead-ends are to be only used for light applications such as new strand with a small light 144 count fiber or smaller

• For use on extra-high-strength, high-strength, Siemens Martin, utilities-grade, galvanized steel strand, performance match Bezinal, GUY-GRIP dead-ends, false dead-ends and strand splices available.
• The Guy Grip is intended for use on single wood pole associated with distribution construction. They are made of the same material as the strand to which they are applied and are rated at 100% of the strands published rated breaking strength
• Size: 1/4"
• Mean Diameter: .259"
• Length: 25"

One-piece V-type crossarm brace is fabricated from angle steel and provides heavy-duty support for crossarm stability.

• 75" length end-to-end
• 9/16" crossarm mouinting hole
• 11/16" pole mounting hole
• In compliance with ANSI C135.6 specification
• Galvanized per ASTM A-153

HDG Communication Arm 3 & 2 - Position Steel Under-build, 15° Angled
15 degree angled Communication Arm 3 & 2 position Steel Under-build, galvanized for weather protection, and designed to allow for the addition of under-build cables. 36" & 24" in length from pole and 12" between mount holes.
All pole mounting and cable mounting holes are 11/16'' diameter.
WSO WB2751-B-HDG

The manhole cable roller leads the cable from the drum into the jointbox/manhole or the winch bond out of the manhole.

Slingco makes utility pole framing and installation easier and more cost-effective than ever.
Slingco stores flat on any work vehicle and — with a few twists — transforms into the industry's most helpful device. Whether you're performing regularly scheduled pole replacement or if you're reacting to a natural disaster, Slingco gets the job done safer, faster and easy.
COMPACT: Folds to 3” x 23” x 30” for easy storage.
LIGHTWEIGHT: Only weighs 33 pounds.
STRONG: Supports poles from 30’ to 70’.
STABLE: Stays put on even and uneven ground.
Poleprop Utility Pole Framing

To be used with Manta Ray MR2, MR1, MRSR, or Pisa type power driven solid core or socket drive anchors only. Use with H-J12585-D6567-EYENUT for-Pisa-Rod only.

9053 E Lashing wire clamp Used to secure a terminating lashing wire to the strand. Comprised of a one-piece jaw, two washers, two nuts, and a square shank stud. Bug Nut
Bugnut also stock Hubbell 9000 E Clamp

Hex head lag screws with steal neoprene washers are ideal to secure plastic U-cable guards. 9/16" steel washer is bonded with....

Used to secure a tap or other electronic device to strand. Consists of a set of aluminum jaws, a perforated aluminum bracket, a carriage bolt and...

Hex head lag screws with steal neoprene washers are ideal to secure plastic U-cable guards. 9/16" steel washer is bonded with....

• Used to secure figure 8 cable to telephone poles. Bitch clamp

• Each Suspension Clamp is comprised of two aluminum plates, two 1/2" carriage bolts, and two square nuts.

• The plates are extruded and stamped from 6063-T6 Aluminum.

• Center hole accommodates 5/8" bolts.

• Figure 8 Three-Bolt Suspension Clamps are 6" long.

• Carriage bolt and nuts are formed from Grade 2 Steel.

• Carriage bolts and square nuts are hot dip galvanized to meet ASTM Specification A153, Class C.

Used to secure a tap or other electronic device to strand. Consists of a bracket, a set of mating jaws, a carriage bolt and...

J hooks are used for supporting bail-type drop wire and deadend clamps from poles and crossarms.

J hooks are used for supporting bail-type drop wire and deadend clamps from poles and crossarms.

H-854 /SI-2006 SPLIT BOLT
Allied Bolt Part # 854

• Used to make a bonding connection between two copper ground wires.
• Bolt and nut formed from high-strength corrosion resistant C210 Copper.
• Specially designed pressure bar provides high pull-out strength.
• Under torque, provides high contact pressure between ground wires.
• Smallest two conductors accepted: 10 Sol.
• Largest two conductors accepted: 6 Sol.
• Min. wire size that can be used with Max. wire size: 16 Sol.
• Tested and UL listed to UL486A requirements.

FITS POLES 12"-16" DIAMETER H-J6684 •Adjustable Pole Bands provide attachment points for guys and suspension insulators with J6650 Connecting Link •Each Adjustable Pole Band Assembly contains four 1/4" x 4" stampings, four 3/4" threaded studs, and sixteen 3/4" Regular Square Nuts. •Each stamping has a 9/16" square hole. All components hot dip galvanized to meet ASTM Specification A153. Hot Dip Galvanized J6650 Connecting Link Mounting Positions: All Four Sides. Use with H-J6650 Connecting Link & H-J6288 GUY ROLLER, H-CP-6-30 CLEVIS PIN 3/4" x 2.5" and M-111-2A cotter Pin must buy seperately

POLE BAND H-J6684 FITS POLES 12"-16" DIAMETER

The semi-Tin plated Bronze Bonding Clamp assembly consists of two clamp sections and a 5/16 x 7/8-inch bronze hex washer head bolt.
One clamp section is tapped to allow installation with a single wrench.

Cable suspension clamp - Straight H-J7904-ALL-5087 13/16" hole 3/4" hardware MPS cable suspension clamps are used with through bolts which serve as a clamping member and are shaped to securely grip messenger wire/strand to the pole.

• Used to secure figure 8 cable to telephone poles.
• Each Suspension Clamp is comprised of two aluminum plates, two 1/2" carriage bolts, and two square nuts.
• The plates are extruded and stamped from 6063-T6 Aluminum.
• Center hole accommodates 5/8" bolts.
• Figure 8 Three-Bolt Suspension Clamps are 6" long.
• Carriage bolt and nuts are formed from Grade 2 Steel.
• Carriage bolts and square nuts are hot dip galvanized to meet ASTM Specification A153.

D Cable Lashing Clamp used in aerial construction to secure terminating lashing wire or ground wire to a strand Attaches to 1/4"(6mm) to 7/16" (16mm) Made in the USA

Used to support CATV and telephone cables from the strand. The end of the strap is tapered to provide easy installation into....

Used to support CATV and telephone cables from the strand. The end of the strap is tapered to provide easy installation into...

Used to support CATV and telephone cables from the strand. The end of the strap is tapered to provide easy installation into....

Used to support CATV and telephone cables from the strand. The end of the strap is tapered to provide easy installation into...

Kinsel Saddle type spacer Used in lashed cable construction to provide a separation between the cable and strand. A slot is provided to guide and secure lashed cable supports.

AB strap buckles are used in conjunction with cut lengths of ab straps for supporting telephone cables to strand. The buckle consists of a high-strength molded plastic head with two sets of stamped teeth inserted on opposite ends for accepting opposite ends of strap. Locking teeth in buckle are hardened 301 stainless steel.
(Sold In Bags of 25)

ABstrap spacers are used in conjunction with lashing straps to provide a desired spacing between a strand and cable. The spacers are...

Used in conjunction with buckles (part no. 1072) to support cables from strand. abstrap reels are uncut 50 foot lengths of plastic lashing strap. no sharp edges for installer to cut hands on while tensioning. the strapping is housed in a plastic reel that makes dispensing easy. Highly resistant to both UV (ultra violet) light and weather changes. High tensile strength after fastening.

Used in lashed cable construction to provide a separation between the cable and strand. A slot is provided to guide and secure ...

Aluma-Form 29556 Carriage Bolt 1/2" x 2"
The carriage bolts are roll threaded with square shoulder and square nut for Stand Off Bracket

• Supplied Assembled with Square Nut
• Rolled Threads
• Square Shoulder
• Hot dip galvanized to meet ASTM A153

Aluma-Form 6" Riser x 6" wide 6B-CSO-6 Band-able Standoff Bracket with an 6" wide 2-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting 1” through 2.5” conduit in a variety of ways. This bracket has a wide range of adjustability. T-slot extrusion eliminates field drilling. Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and 1/2” lag screw, Can also be banded. Pipe straps & Banded Buckle sold separately. One Band and buckle required for all 6B-CSO Standoff banded brackets.
Not wide enough for a 3" or 4" Pipe Strap

Aluma-Form 6" Riser x 8" wide 6B-CSO-8 Band-able Standoff Bracket with an 8" wide 2-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting 1” through 4” conduit in a variety of ways. This bracket has a wide range of adjustability. T-slot extrusion eliminates field drilling. Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and 1/2” lag screw, Can also be banded. Pipe straps & Banded Buckle sold separately. One Band and buckle required for all 6B-CSO standoff banded brackets.

ALU RA 6018 WOOD BRACE PAIR REVERSABLE
Aluma-Form braces feature end fittings of extruded aluminum 6061-T6 alloy that eliminates the need for bolted fittings. The greater shear and friction area gripped by the Aluma-Form end fitting allows the use of smaller wood members thereby reducing weight and producing a more eye pleasing brace that is stronger than bolted fittings.

34-31/32 HOLE to HOLE
9/16 HOLE IN ANGLED END
11/16 HOLE IN STRAIGHT END
WOOD IS 27-5/8 LONG 1-3/4 X 1-3/4

High Density APITONG BRACES Cross Section 1-3/4” x 1-3/4” Hole Size 9/16” at arm 11/16” at pole.

Aluma-Form 6" Riser x 8" wide 6B-CSO-8-4WT  Band-able Standoff Bracket with
an 8" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting
1” through 4” conduit in a variety of ways. This bracket has a wide
range of adjustability. T-slot extrusion eliminates field drilling.
Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and
1/2” lag screw, Can also be banded. Pipes straps & Banded Buckle sold separately. One Band and buckle required for all 6B-CSO standoff banded brackets.

Aluma-Form band used to wrap around poles to hold attachments 100ft length. 3/4" wide x .30 x 100ft length. Without drilling holes, Bolt-A-Band features a pre-cut, high quality stainless steel band with accompanying installation hardware. Adjust easily to fit most any size pole. Installs in just minutes with no special tools required.
Two buckles required for all band brackets and attachments.

T-SLOT 4 WAY CHANNEL ONLY 12" SOLD EA.
Used with Alumaform Standoff Brackets

T-SLOT 4 WAY CHANNEL ONLY 24" SOLD EA.
Used with Alumaform Standoff Brackets

T-SLOT 4 WAY CHANNEL ONLY 36" SOLD EA.
Used with Alumaform Standoff Brackets

T-SLOT 4 WAY CHANNEL ONLY 8" SOLD EA.
Used with Alumaform Standoff Brackets

Aluma-Form 6" Riser x 6" wide 6B-CSO-6-4WT Band-able Standoff Bracket with an 6" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting 1” through 2.5” conduit in a variety of ways. This bracket has a wide range of adjustability. T-slot extrusion eliminates field drilling. Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and 1/2” lag screw, Can also be banded. Pipe straps & Banded Buckle sold separately. One Band and buckle required for all 6B-CSO standoff banded brackets. Not wide enough for a 3" or 4" Pipe Strap

Aluma-Form 6" Riser x12" wide 6B-CSO-12 Band-able Standoff Bracket with an 12" wide 2-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting 1” through 6” conduit in a variety of ways. This bracket has a wide range of adjustability. T-slot extrusion eliminates field drilling. Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and 1/2” lag screw, Can also be banded. Pipe Straps & Banded Buckle sold separately.
One Band and buckle required for all 6B-CSO standoff banded brackets.

Aluma-Form 6" Riser x 12" wide 6B-CSO-12-4WT Band-able Standoff Bracket with an 6" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting 1” through 4” conduit in a variety of ways. This bracket has a wide range of adjustability. T-slot extrusion eliminates field drilling. Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and 1/2” lag screw, Can also be banded. Pipe Straps & Banded Buckle sold separately. One Band and buckle required for all 6B-CSO standoff banded brackets.

Aluma-Form 6" Riser x 18" wide 6B-CSO-18-4WT Band-able Standoff Bracket with an 18" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting 1” through 4” conduit in a variety of ways. This bracket has a wide range of adjustability. T-slot extrusion eliminates field drilling. Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and 1/2” lag screw, Can also be banded. Pipe Straps & Banded Buckle sold separately.
One Band and buckle required for all 6B-CSO standoff banded brackets.

Aluma-Form 6" Riser x 24" wide 6B-CSO-24-4WT  Band-able Standoff Bracket with
an 6" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting
1” through 4” conduit in a variety of ways. This bracket has a wide
range of adjustability. T-slot extrusion eliminates field drilling.
Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and
1/2” lag screw, Can also be banded. Pipe Straps & Banded Buckle sold separately. One band and buckle required for all 6B-CSO standoff banded brackets.

T-SLOT 4 WAY CHANNEL ONLY 48" SOLD EA.
Used with Alumaform Standoff Brackets

Aluma-Form 6" Riser x 36" wide 6B-CSO-36-4WT  Band-able Standoff Bracket with
an 6" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting
1” through 4” conduit in a variety of ways. This bracket has a wide
range of adjustability. T-slot extrusion eliminates field drilling.
Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and
1/2” lag screw, Can also be banded. Pipe Straps & Banded Buckle sold separately. One band and buckle required for all 6B-CSO standoff banded brackets.

Model CS-820 universally accept outside cable diameters from 3/4” to 3” (19mm to 76mm)
Easily installed units that consist of an aluminum saddle, a polyethylene foam double coated bonding tape with pressure sensitive synthetic polymer (rubber based) adhesive, and a helically cut polyethylene cable tie.

BAND-IT 201 Stainless Steel Band 5/8" X 100' BAND-C20599STANDARD BOX

BAND-IT 201 Stainless Steel Band 3/4" X 100' BAND C20699 STANDARD BOX
Now with EASY SCALE, a patented imprint on the band to determine band length. Eliminates costly waste and complicated measuring by allowing users to quickly and precisely roll out the length of band needed for any clamp. No more guesswork!

EASY SCALE®, a patented imprint on the band to determine band length. Eliminates costly waste and complicated measuring by allowing users to quickly and precisely roll out the length of band needed for any clamp.

BAND-IT Ear-Lokt Buckles can be used with many types of stainless-steel banding providing superior fastening strength. 100 box

• Ear-Lokt style buckle for standard duty applications including hose assemblies, cable bundling and general fastening
• 201 Stainless Steel offers good resistance to oxidation and many moderate corrosive agents
• Can hold a single or double wrapped band configuration
• Band clamps can be formed over any contour or shape
• Can be applied on BAND-IT® band with the following BAND-IT® tools: C00169, C00369, C07569
