DEADEND BRACKET SF-YDB
ROLLER ASSEMBLIES ON EACH SIDE. 2" X 3/8 X 40-3/4 WITH 11/16 HOLE EACH SIDE 20.38 LONG USED FOR DEAD-END APPLICATIONS WITH WIRE FORMS OR STRAND VISE ON OPPOSING SIDES OF POLES YOKE or DEADEND BRACKET SF-YDB
Klein 66090 2-In-1 Slotted Impact Socket Set, 12-Point, 6-Piece
Klein Tools 2-In-1 Slotted Impact Socket Set, 12-Point, 6-Piece
- Twelve sizes combined into six sockets including: 1-1/8 x 15/16-Inch, 1 x 13/16-Inch, 7/8 x 11/16-Inch, 3/4 x 9/16-Inch, 5/8 x 7/16-Inch, and 1/2 x 3/8-Inch
- 1-1/8 x 15/16-Inch and 3/4 x 9/16-Inch impact sockets features an alignment slot to tighten and loosen most pole hardware
- Single-ended impact socket wrenches with hands free adjustment between socket sizes
- Two coaxial spring loaded sockets in one tool
- Sockets have a high-torque, 12-Point design making it easier to position on fasteners
- Deep socket with a 1/2-Inch drive works great for pole hardware installation and removal
- Cross hole design helps maintain socket connection to adapter or impact wrench
- Engineered for use with impact wrenches including Klein's 1/2-Inch Compact Impact Wrench (Cat. Nos. BAT20-CW, BAT20-CW1)
- Sockets are color coded to quickly identify slotted and sizes
- Includes case for storage
Wall Strap 9/16 Hole J7692 8" Long
Used to terminate strand at a right angle to the building wall. A wire rope thimble is recommended to protect the strand when using the wall strap. 1 7/32 X 15/64 x 8" Long W 9/16 HOLES J7692
Wall Strap 24-3/8" Long Thimble Eye J7696
Wall straps are used for guying and deadending messenger strand to building walls.
- 24-3/8" Wall Strap Long Thimble eye
- 2-9/16" diameter holes spaced
- 8" from center to center.
Oval Eyenut 3/4" J1093 for 3/4" Hardware
Not for any type of anchor rods. Oval eyenuts are used for deadending with suspension or strain insulators. Oval eye nuts are tapped to fit hot dip galvanized bolts made to ANSI Specifications and are designed to develop strength ratings consistent with the bolts with which they are used.
Thimble Eyenut 3/4" J6511 for 3/4" Hardware
Not for any type of anchor rods. 3/4" Thimble eyenuts are tapped to fit hot dip galvanized bolts made to ANSI Specifications and are designed to develop strength ratings consistent with the bolts with which they are used.
Thimble eye nuts are used for span, head and stub guying.
3/8" WIRE ROPE THIMBLE J1057
Used in guying applications to form an oval wire eye for securing to eye-bolts and guy rods.
- Thimble, Wire Rope: Type - Guy Open Wire Rope
- Strand Diameter - 3/8 in
- Opening Width - 5/8 in
- Eye Width - 7/8 in
- Eye Length - 1 7/8 in
- Material - Steel, Hot Dipped Galvanized
- Weight - 8.80 lb/100.
THIMBLE OPEN 3/8 Guy Strand J1057
1/2" WIRE ROPE THIMBLE J1058
Used in guying applications to form an oval wire eye for securing to eye-bolts and guy rods.
- Thimble, Wire Rope: Type - Guy Open Wire Rope
- Strand Diameter - 1/2 in
- Opening Width - 3/4 in
- Eye Width - 1 1/8 in
- Eye Length - 2 in
- Material - Steel, Hot Dipped Galvanized
- Weight - 18.40 lb/100
THIMBLE OPEN 1/2 Guy Strand J1058
ANGLE THIMBLE EYELET 5/8" J6500
Features: Eyelets, also known as Bolt Eyes, are used under the head or nut of a bolt. All are compatible with the strength of the bolts used with them. Straight thimble eyelets are used for span guys while angle thimble eyelets are used for down guys. Standard eyelets are used for deadending.Standard eyelets and straight thimble eyelets have a slotted hole for ease in inserting the bolt.
| Angle Thimble Eyelets |
|---|
| Catalog Number | Bolt Diameter (Inches) | Max Strand | Weight/100 (lbs) |
|---|
| J6500 | 5/8 | 1/2 | 127
|
ANGLE THIMBLE EYELET H-J6500
Thimble Eyenut 5/8" J6510 for 5/8" Hardware
Not for any type of anchor rods. Thimble Eyenut 5/8" J6510 Thimble eyenuts are tapped to fit hot dip galvanized bolts made to ANSI Specifications and are designed to develop strength ratings consistent with the bolts with which they are used.Thimble eyenuts are used for span, head and stub guying.
Thimble Eyenut 5/8" J6510
Oval Eyenut 5/8" J1092 for 5/8" Hardware
Not for any type of anchor rods. Oval eyenuts are used for deadending with suspension or strain insulators. Oval eyenuts are tapped to fit hot dip galvanized bolts made to ANSI Specifications and are designed to develop strength ratings consistent with the bolts with which they are used.
THIMBLE EYENUT Twin Eyenut 3/4" J6516/All 5046 for 3/4" Hardware
Not for any Anchor Rods Twin eyenuts are tapped to fit hot dip galvanized bolts made to ANSI Specifications and are designed to develop strength ratings consistent with the bolts with which they are used.
Twin eye nuts accommodate double guys. J6516 /All 5046Twin eye nut
ANGLED SINGLE STRAND EYELET 3/4" H-J6501/ALL2061
3/4" ANGLED SINGLE STRAND EYELET for 3/4" Hardware
Straight thimble eyelets are used for span guys while angle thimble eyelets are used for down guys. Standard eyelets are used for deadending. Standard eyelets and straight thimble eyelets have a slotted hole for ease in inserting the bolt.
Allied Bolt part# 2061 Older Maclean part# was a J6501
Used with machine bolts or eyebolts for down guying.
Forged from high strength AISI 1018 Steel.
Hot dip galvanized to meet ASTM Specification A153.
Ultimate tensile strength is 45° is 28,000.
5/8 X 10" OVAL EYE BOLT H-J9410
OVAL EYE BOLT H-J9410 5/8 X10"
Eyebolts are forged, one piece design and are commonly used as an attachment point to secure thimbles, clevises, links and deadend insulators. Regular oval eyebolts are supplies with a 4 or 6 inch thread length and one assembled square nut.
Eye I.D. 1-1/2" width x 2" length
5/8 X 12" OVAL EYE BOLT H-J9412
OVAL EYE BOLT H-J9412 5/8 X12"
Eyebolts are forged, one piece design and are commonly used as an attachment point to secure thimbles, clevises, links and deadend insulators. Regular oval eyebolts are supplies with a 4 or 6 inch thread length and one assembled square nut.
Eye I.D. 1-1/2" width x 2" length
OVAL EYE BOLT H-J9416 5/8 X16"
OVAL EYE BOLT H-J9416 5/8 X16"
Eyebolts are forged, one piece design and are commonly used as an attachment point to secure thimbles, clevises, links and deadend insulators. Regular oval eyebolts are supplies with a 4 or 6 inch thread length and one assembled square nut.
Eye I.D. 1-1/2" width x 2" length
5/8 X 18" OVAL EYE BOLT J9418
OVAL EYE BOLT H-J9418 5/8 X18"
Eyebolts are forged, one piece design and are commonly used as an attachment point to secure thimbles, clevises, links and deadend insulators. Regular oval eyebolts are supplies with a 4 or 6 inch thread length and one assembled square nut.
Eye I.D. 1-1/2" width x 2" length
5/8 x 8" OVAL EYE BOLT H-J9408
OVAL EYE BOLT H-J9408 5/8 X8"
Eyebolts are forged, one piece design and are commonly used as an attachment point to secure thimbles, clevises, links and deadend insulators. Regular oval eyebolts are supplies with a 4 or 6 inch thread length and one assembled square nut.
Eye I.D. 1-1/2" width x 2" length
Triple Eyenut 1" J12585
Used Only in conjunction with PISA D100 1" Anchor rods , D10031C 1" x 3-1/2ft or D75 rod for helical and Manta Ray anchors.
Straight Thimble Slip Eye 5/8" J6550C for 5/8" Hardware
Not for any type of anchor rods. Straight Thimble Slip Eye J6551 Eyelets, also known as Slip eyes, are used under the head or nut if a bolt. Straight thimble eyelets are used for span guys. Mounting Bolt Hole: 1"x 11/16". Bolt Size: 5/8.
Straight Thimble Slip Eye J6550C
SHOULDER EYEBOLT 3/4"X16" J9536
SHOULDER EYEBOLT 3/4 INCH DIAMETER, MINIMUM TENSILE STRENGTH 20,050 LBS
Eyebolts are forged, one piece design and are commonly used as an attachment point to secure thimbles, clevises, links and deadend insulators. Regular oval eyebolts are supplies with a 4 or 6 inch thread length and one assembled square nut.
5/8 X 24" OVAL EYE BOLT J9424
OVAL EYE BOLT H-J9414 5/8 X24"
Eyebolts are forged, one piece design and are commonly used as an attachment point to secure thimbles, clevises, links and deadend insulators. Regular oval eyebolts are supplies with a 4 or 6 inch thread length and one assembled square nut.
- Hot Dip Galvanized
- 6" thread length
- Includes one square nut
- Eye dimensions are 5/8" x 1 1/2" x 2"
- Rated tensile strength is 13,550 lbs.
- Galvanized steel per ASTM A-153
- Manufactrured in compliance with ANSI C135.4 and C135.5
- RUS listed o - Bolt, eye, oval
5/8 X 14" OVAL EYE BOLT J9414
OVAL EYE BOLT H-J9414 5/8 X14"
Eyebolts are forged, one piece design and are commonly used as an attachment point to secure thimbles, clevises, links and deadend insulators. Regular oval eyebolts are supplies with a 4 or 6 inch thread length and one assembled square nut.
Eye I.D. 1-1/2" width x 2" length
5/8 X 22" OVAL EYE BOLT J9424
OVAL EYE BOLT H-J9414 5/8 X22"
Eyebolts are forged, one piece design and are commonly used as an attachment point to secure thimbles, clevises, links and deadend insulators. Regular oval eyebolts are supplies with a 4 or 6 inch thread length and one assembled square nut.
- Hot Dip Galvanized
- 6" thread length
- Includes one square nut
- Eye dimensions are 5/8" x 1 1/2" x 2"
- Rated tensile strength is 13,550 lbs.
- Galvanized steel per ASTM A-153
- Manufactrured in compliance with ANSI C135.4 and C135.5
- RUS listed o - Bolt, eye, oval
