AB STRAP Without Buckle 50' 1075
Used in conjunction with buckles (part no. 1072) to support cables from strand. abstrap reels are uncut 50 foot lengths of plastic lashing strap. no sharp edges for installer to cut hands on while tensioning. the strapping is housed in a plastic reel that makes dispensing easy. Highly resistant to both UV (ultra violet) light and weather changes. High tensile strength after fastening.
Antenna Mount Aluma-Form CAM-P-DUY
Antenna mounts are custom designed and manufactured to user specifications using our unique extruded aluminum. The structural members are fabricated using high strength 6061-T6 aluminum alloy (35,000 PSI yield strength) which provides the structural equivalent of steel with 65% less weight. 6061-T6 aluminum is also extremely corrosion resistant.
Banding 1-1/4" x 100' Aluma-Form SSB-100 MADE IN USA (Currently Unavailable)
Aluma-Form band used to wrap around poles to hold attachments 10ft length. 1 1/4" wide 100ft length. Without drilling holes, Bolt-A-Band features a pre-cut, high quality stainless steel band with accompanying installation hardware. Adjust easily to fit most any size pole. Installs in just minutes with no special tools required.
Two buckles required for all band brackets and attachments.
Banding 3/4" x 100' x .30 Aluma-Form 201-SSB-100 MADE IN USA
Aluma-Form band used to wrap around poles to hold attachments 100ft length. 3/4" wide x .30 x 100ft length. Without drilling holes, Bolt-A-Band features a pre-cut, high quality stainless steel band with accompanying installation hardware. Adjust easily to fit most any size pole. Installs in just minutes with no special tools required.
Two buckles required for all band brackets and attachments.
Buckle 1-1/4" Alum-A-Form BAB-58
Bolt Clamp Used to hold together banding around pole with hardware attached without drilling holes. Adjust easily to fit most any size pole. Installs in just minutes with no special tools required. Two buckles required for all banded brackets and attachments
Buckle For 3/4" Banding Aluma-Form BAB-38
Bolt Clamp Used to hold together banding around pole with hardware attached without drilling holes. Adjust easily to fit most any size pole. Installs in just minutes with no special tools required.
Two buckles required for all band brackets and attachments.
Cable Positioners Assemblies/Single Phase Mounts Aluma-Form CS820
Model CS-820 universally accept outside cable diameters from
3/4” to 3” (19mm to 76mm)
Easily installed units that consist of an aluminum saddle, a polyethylene foam double coated bonding tape with pressure sensitive synthetic polymer (rubber based) adhesive, and a helically cut polyethylene cable tie.
Double Banded Standoff Bracket ALU-6B-ASO-8
ALU 6B-ASO-8 Double Banded Standoff Bracket,-WayTslot Band 6"riser8"wide Double Banded Only no thru-bolt No holes for thru-bolt or lags. Used in Heavy duty pole applications.
Banding and Two buckles required for all band brackets and attachments. These items must be purchased separately.
Fiberglass Crossarm Tangent Arm Aluma-Form FTA20-2-48-A 48" Composite Crossarm
Material Specifications Pole Gain , 6061-T6 Aluminum Pole Gain with 8”, 10”, & 12” mounting centers, Accepts 5/8” mounting hardware, Can be banded using the Aluma-Form Bolt-A-Band banding system Fiberglass Composite Tube, 3-5/8” X 4-5/8” Super-Smooth, proprietary veiled gray polyester tube with added ultraviolet protection.
Two buckles required for all band brackets and attachments.
Fiberglass Crossarm Dead End With Eyebolts Aluma-Form FDA-20-2-72-EB-FG 72"
Fiberglass Crossarm Dead End, Material Specifications Pole Gain 65-45-12 Ductile Iron, hot-dipped galvanized per ASTM A153 (12” mounting centers) 2 guy attachment positions rated at 30,000# per hole,Accepts 3/4” pole mounting hardware, Can be banded using the Aluma-Form Bolt-A-Band banding system,Fiberglass Tube 3-5/8” X 4-5/8” Super-Smooth, proprietary veiled gray polyester tube with added ultraviolet protection.
Two buckles required for all band brackets and attachment.
Fiberglass Crossarm Dead End With Eyebolts Aluma-Form FDA-20-2-96-EB-FG 96"
Fiberglass Crossarm, Dead End Material Specifications Pole Gain 65-45-12 Ductile Iron, hot-dipped galvanized per ASTM A153 (12” mounting centers) 2 guy attachment positions rated at 30,000# per hole,Accepts 3/4” pole mounting hardware, Can be banded using the Aluma-Form Bolt-A-Band banding system,Fiberglass Tube 3-5/8” X 4-5/8” Super-Smooth, proprietary veiled gray polyester tube with added ultraviolet protection.
Two buckles required for all band brackets and attachments.
Fiberglass Crossarm Tangent Arm Aluma-Form FTA20-4-120-A 10ft Composite Crossarm
Fiberglass Crossarm Tangent Arm Aluma-Form FTA20-4-120-A Composite Cross-arm
120" (10ft) x-arm Xarm
Material Specifications Pole Gain
• 6061-T6 Aluminum Pole Gain
with 8”, 10”, & 12” mounting
centers
• Accepts 5/8” mounting hardware
• Can be banded using the
Aluma-Form Bolt-A-Band
banding system
Fiberglass Tube
• 3-5/8” X 4-5/8” Super-Smooth,
proprietary veiled gray polyester
tube with added ultraviolet
protection
Two buckles required for all banded brackets and attachments.
Fiberglass Crossarm Tangent Arm Aluma-Form FTA20-4-72-A
Material Specifications Pole Gain
• 6061-T6 Aluminum Pole Gain
with 8”, 10”, & 12” mounting
centers
• Accepts 5/8” mounting hardware
• Can be banded using the
Aluma-Form Bolt-A-Band
banding system
Fiberglass Tube
• 3-5/8” X 4-5/8” Super-Smooth,
proprietary veiled gray polyester
tube with added ultraviolet
protection
Two buckles required for all band brackets and attachments.
Fiberglass Crossarm Tangent Arm Aluma-Form FTA20-4-96-A Composite Crossarm
Fiberglass Crossarm Tangent Arm Aluma-Form FTA20-4-96-A Composite Crossarm
Material Specifications Pole Gain
• 6061-T6 Aluminum Pole Gain
with 8”, 10”, & 12” mounting
centers
• Accepts 5/8” mounting hardware
• Can be banded using the
Aluma-Form Bolt-A-Band
banding system
Fiberglass Tube
• 3-5/8” X 4-5/8” Super-Smooth,
proprietary veiled gray polyester
tube with added ultraviolet
protection
Two buckles required for all banded brackets and attachments.
Fiberglass Equipment Mount 15° 24" Mount Aluma-Form F1CA-MV-A24-F2
Single Phase/Cable Support 15 Degree Mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53
(6" to 8" mounting centers) Accepts 5/8" pole mounting hardware.
Can be banded using the Aluma-Form Bolt-A-Band banding system.
End Fitting
65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153
Fiberglass Rod
1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added
ultraviolet protection.
Rod Diameter - 1 1/2"
length - 24"
Two bands and buckles required for banded installation. Not included.
Fiberglass Equipment Mount 15° 36" Mount Aluma-Form F1CA-MV-A36-F2
Single Phase/Cable Support 15 Degree Mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53
(6" to 8" mounting centers) Accepts 5/8" pole mounting hardware.
Can be banded using the Aluma-Form Bolt-A-Band banding system.
End Fitting
65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153
Fiberglass Rod
1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added
ultraviolet protection.
Rod Diameter - 1 1/2"
length - 36" Two buckles required for all banded brackets and attachments.
Fiberglass Equipment/Standoff Mount 0° 12" Aluma-Form F1CA-MV-H12-F2
Single Phase/Cable Support 0 Degree Mount
65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53
(6" to 8" mounting centers) Accepts 5/8" pole mounting hardware.
Can be banded using the Aluma-Form Bolt-A-Band banding system.
End Fitting
65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153.
Includes 5/8" x2" bolt, lock washer with nut.
Fiberglass Rod
1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added
ultraviolet protection.
Rod Diameter 1 - 1/2
Length 12"
Weight - 6.3LBS
Two buckles required for all band brackets and attachments.
Fiberglass Equipment/Standoff Mount 0° 18" Aluma-Form F1CA-MV-H18-C7
Single Phase/Clover Leaf 7-Hole 18"
65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A153
(6" to 8"" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form
Bolt-A-Band Banding system.
Two buckles required for all band brackets and attachments.
Fiberglass Equipment/Standoff Mount 0° 18" Aluma-Form F1CA-MV-H18-F2
Single Phase/Cable Support 0degree mount
65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53
(6" to 8" mounting centers) Accepts 5/8" pole mounting hardware.
Can be banded using the Aluma-Form Bolt-A-Band banding system.
End Fitting
65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153.
Includes 5/8" x2" bolt, lock washer with nut.
Fiberglass Rod
1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added
ultraviolet protection.
Rod Diameter 1 - 1/2
Length 18"
Weight - 7LBS
Two buckles required for all band brackets and attachments.
Fiberglass Equipment/Standoff Mount 15 Degree 30" Mount Aluma-Form F1CA-MV-A30-F2
30" ALU F1CA-MV-A30-F2 FIBERGLASS
Single Phase/Cable Support 15 Degree Mount
65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53
(6" to 8" mounting centers) Accepts 5/8" pole mounting hardware.
Can be banded using the Aluma-Form Bolt-A-Band banding system.
End Fitting
65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153
Fiberglass Rod
1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added
ultraviolet protection.
Rod Diameter - 1 1/2" Two buckles required for all banded brackets and attachments.
Fiberglass Equipment/Standoff Mount 15° 12" Aluma-Form F1CA-MV-A12-F2
Single Phase/Cable Support 15 Degree Mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53
(6" to 8" mounting centers) Accepts 5/8" pole mounting hardware.
Can be banded using the Aluma-Form Bolt-A-Band banding system.
End Fitting
65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153
Fiberglass Rod
1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added
ultraviolet protection.
Rod Diameter - 1 1/2"
length - 12"
Two buckles required for all band brackets and attachments.
Fiberglass Equipment/Standoff Mount 15° 18" Aluma-Form F1CA-MV-A18-C7
Clover Leaf 7-Hole Cable Support 15 Degree Mount Ductile Iron, Hot-dipped galvanized per ASTM A!53
(6" to 8" mounting centers) Accepts 5/8" pole mounting hardware.
Can be banded using the Aluma-Form Bolt-A-Band banding system.
End Fitting
65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153
Fiberglass Rod
1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added
ultraviolet protection.
Two buckles required for all band brackets and attachments.
Fiberglass Equipment/Standoff Mount 15° 18" Aluma-Form F1CA-MV-A18-F2
18" Single Phase/Cable Support 15 Degree Mount
65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53
(6" to 8" mounting centers) Accepts 5/8" pole mounting hardware.
Can be banded using the Aluma-Form Bolt-A-Band banding system.
End Fitting
65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153
Fiberglass Rod
1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added
ultraviolet protection.
Rod Diameter - 1 1/2"
length - 18"
Two buckles required for all band brackets and attachment.
Fiberglass Equipment/Standoff Mount 15° 24" Mount Aluma-Form F1CA-MV-A24-BF2
24" ALU F1CA-MV-A24-BF2 FIBERGLASS
Single Phase/Cable Support 15 Degree Mount
65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53
(6" to 8" mounting centers) Accepts 5/8" pole mounting hardware.
Can be banded using the Aluma-Form Bolt-A-Band banding system.
End Fitting
65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153
Fiberglass Rod
1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added
ultraviolet protection.
Rod Diameter - 1 1/2"
length - 24"
Two buckles required for all band brackets and attachments.
Fiberglass Equipment/Standoff Mount 15° 30" Mount Aluma-Form F1CA-MV-A30-BF2
30" ALU F1CA-MV-A30-BF2 FIBERGLASS
Single Phase/Cable Support 15 Degree Mount
65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53
(6" to 8" mounting centers) Accepts 5/8" pole mounting hardware.
Can be banded using the Aluma-Form Bolt-A-Band banding system.
End Fitting
65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153
Fiberglass Rod
1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added
ultraviolet protection.
Rod Diameter - 1 1/2" Length Two buckles required for all banded brackets and attachments.
Fiberglass Single Phase/Clover Leaf 7-Hole 15° Mount 1.5"X12" Aluma-Form F1CA-MV-A12-C7
Clover Leaf 7-Hole Cable Support 15 Degree Mount Ductile Iron, Hot-dipped galvanized per ASTM A!53
(6" to 8" mounting centers) Accepts 5/8" pole mounting hardware.
Can be banded using the Aluma-Form Bolt-A-Band banding system.
End Fitting
65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153
Fiberglass Rod
1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added
ultraviolet protection.
Standoff Length: 12" Two buckles required for all banded brackets and attachments.
Workload:
P1(lbs) 1,800
P2(lbs) 1,400
P3(lbs) 10,000
Fiberglass Single Phase/Clover Leaf 7-Hole 15° Mount 1.5"X18" Aluma-Form F1CA-MV-A18-C7H
Clover Leaf 7-Hole Cable Support 15 Degree Mount Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-18 Ductile Iron, Hot dipped galvanized per ASTM A153 Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection.
Standoff Length: 18" Two buckles required for all banded brackets and attachments.
Workload:
P!(lbs) 1,200
P2(lbs) 900
P3(lbs) 10,000
Standoff Bracket Aluma-Form 6B-CSO-12 2-Way
Aluma-Form 6" Riser x12" wide 6B-CSO-12 Band-able Standoff Bracket with an 12" wide 2-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting 1” through 6” conduit in a variety of ways. This bracket has a wide range of adjustability. T-slot extrusion eliminates field drilling. Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and 1/2” lag screw, Can also be banded. Pipe Straps & Banded Buckle sold separately.
One Band and buckle required for all 6B-CSO standoff banded brackets.
Standoff Bracket Aluma-Form 6B-CSO-12-4WT
Aluma-Form 6" Riser x 12" wide 6B-CSO-12-4WT Band-able Standoff Bracket with an 6" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting 1” through 4” conduit in a variety of ways. This bracket has a wide range of adjustability. T-slot extrusion eliminates field drilling. Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and 1/2” lag screw, Can also be banded. Pipe Straps & Banded Buckle sold separately. One Band and buckle required for all 6B-CSO standoff banded brackets.
Standoff Bracket Aluma-Form 6B-CSO-18-4WT
Aluma-Form 6" Riser x 18" wide 6B-CSO-18-4WT Band-able Standoff Bracket with
an 18" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting
1” through 4” conduit in a variety of ways. This bracket has a wide
range of adjustability. T-slot extrusion eliminates field drilling.
Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and
1/2” lag screw, Can also be banded. Pipe Straps & Banded Buckle sold separately.
One Band and buckle required for all 6B-CSO standoff banded brackets.
Standoff Bracket Aluma-Form 6B-CSO-24-4WT
Aluma-Form 6" Riser x 24" wide 6B-CSO-24-4WT Band-able Standoff Bracket with
an 6" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting
1” through 4” conduit in a variety of ways. This bracket has a wide
range of adjustability. T-slot extrusion eliminates field drilling.
Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and
1/2” lag screw, Can also be banded. Pipe Straps & Banded Buckle sold separately. One band and buckle required for all 6B-CSO standoff banded brackets.
Standoff Bracket Aluma-Form 6B-CSO-36-4WT
Aluma-Form 6" Riser x 36" wide 6B-CSO-36-4WT Band-able Standoff Bracket with
an 6" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting
1” through 4” conduit in a variety of ways. This bracket has a wide
range of adjustability. T-slot extrusion eliminates field drilling.
Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and
1/2” lag screw, Can also be banded. Pipe Straps & Banded Buckle sold separately. One band and buckle required for all 6B-CSO standoff banded brackets.
Standoff Bracket Aluma-Form 6B-CSO-6 2-Way
Aluma-Form 6" Riser x 6" wide 6B-CSO-6 Band-able Standoff Bracket with
an 6" wide 2-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting
1” through 2.5” conduit in a variety of ways. This bracket has a wide
range of adjustability. T-slot extrusion eliminates field drilling.
Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and
1/2” lag screw, Can also be banded. Pipe straps & Banded Buckle sold separately. One Band and buckle required for all 6B-CSO Standoff banded brackets.
Not wide enough for a 3" or 4" Pipe Strap
Standoff Bracket Aluma-Form 6B-CSO-6-4WT
Aluma-Form 6" Riser x 6" wide 6B-CSO-6-4WT Band-able Standoff Bracket with
an 6" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting
1” through 2.5” conduit in a variety of ways. This bracket has a wide
range of adjustability. T-slot extrusion eliminates field drilling.
Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and
1/2” lag screw, Can also be banded. Pipe straps & Banded Buckle sold separately. One Band and buckle required for all 6B-CSO standoff banded brackets. Not wide enough for a 3" or 4" Pipe Strap
Standoff Bracket Aluma-Form 6B-CSO-8 2-Way
Aluma-Form 6" Riser x 8" wide 6B-CSO-8 Band-able Standoff Bracket with an 8" wide 2-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting 1” through 4” conduit in a variety of ways. This bracket has a wide range of adjustability. T-slot extrusion eliminates field drilling. Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and 1/2” lag screw, Can also be banded. Pipe straps & Banded Buckle sold separately. One Band and buckle required for all 6B-CSO standoff banded brackets.
Standoff Bracket Aluma-Form 6B-CSO-8-4WT
Aluma-Form 6" Riser x 8" wide 6B-CSO-8-4WT Band-able Standoff Bracket with
an 8" wide 4-WAY T-SLOT CHANNELL . A multi-purpose bracket for mounting
1” through 4” conduit in a variety of ways. This bracket has a wide
range of adjustability. T-slot extrusion eliminates field drilling.
Mounts to the pole on 3-5/8” hole centers with 5/8” through bolt and
1/2” lag screw, Can also be banded. Pipes straps & Banded Buckle sold separately. One Band and buckle required for all 6B-CSO standoff banded brackets.
STANDOFF CONDUIT STRAP 1" FOR ALU STK-1
1" CONDUIT STRAP FOR STANDOFF ALU STK-1 INCLUDES 1/2" BOLTS AND NUTS.
Strap kits are available for use with the CSO system with the following variations. The straps have two holes and strap kit consists of straps, bolts, nuts, and washers for mounting one conduit section. These units can also be used with Bolt-A-Band systems to attach to steel or concrete poles.
STANDOFF CONDUIT STRAP 2" FOR ALU STK-2
2" CONDUIT STRAP FOR STANDOFF ALU STK-2 INCLUDES 1/2" BOLTS AND NUTS.
Strap kits are available for use with the CSO system with the following variations. The straps have two holes and strap kit consists of straps, bolts, nuts, and washers for mounting one conduit section. These units can also be used with Bolt-A-Band systems to attach to steel or concrete poles.
STANDOFF CONDUIT STRAP 3" FOR ALU STK-3
3" CONDUIT STRAP FOR STANDOFF ALU STK-3 INCLUDES1/2" BOLTS AND NUTS.
Strap kits are available for use with the CSO system with the following variations. The straps have two holes and strap kit consists of straps, bolts, nuts, and washers for mounting one conduit section. These units can also be used with Bolt-A-Band systems to attach to steel or concrete poles.
STANDOFF CONDUIT STRAP 4" FOR ALU STK-4
4" CONDUIT STRAP FOR STANDOFF ALU STK-4 INCLUDES1/2" BOLTS AND NUTS.
Strap kits are available for use with the CSO system with the following variations. The straps have two holes and strap kit consists of straps, bolts, nuts, and washers for mounting one conduit section. These units can also be used with Bolt-A-Band systems to attach to steel or concrete poles .
STANDOFF CONDUIT STRAP 8" FOR STANDOFF ALU STK-8
8" CONDUIT STRAP FOR STANDOFF ALU STK-8 INCLUDES 1/2" BOLTS AND NUTS.
Strap kits are available for use with the CSO system with the following variations. The straps have two holes and strap kit consists of straps, bolts, nuts, and washers for mounting one conduit section. These units can also be used with Bolt-A-Band systems to attach to steel or concrete poles.
