MSI H-7187, 6-1/2" Wedge Clamp, is mechanical holding device used for strain relief in service applications. It has solid stainless bails that are used on eye hooks and insulators with a diameter larger than 1.5". This clamp is designed for low tension applications only, and also has a mechanical working load of 1,200 lbs.
Specifications/Applications:

• Bail Size: 6-1/2"
• Material: Solid Stainless Steel
• Conductor Diameter Range: 0.250" - 0.414"
• ACSR ASTM-B232: 1/0 - #4
• AAAC ASTM-B399: 1/0 - #4
• AAC ASTM-B231: 2/0 - #2

Allied Bolt 2002 Messenger Grip Drop Clamp

• Used to secure the integrated messenger wires of figure 8 self supporting cables to various house attachments, drive hooks, and span damps
• Clamp grips the messenger jacket on the supporting wire of figure 8 cable, which saves the installer time from having to trip the messenger jacket and pull through a dead-end
• Accommodates support wires ranging in size from .109" - .134"
• Components formed from AISI 1018 steel
• Bail wire formed from 304 stainless steel
• Clamp is mechanically galvanize to meet ASTM specifications B695
• Dead soft stainless Steel Bail wire 9-1/4"
• Steel 1/4"-20X 1-1/4" Carriage Bolt, Flat Washer & Hex nut set
• Steel Jaws for messenger wire of figure 8 cable .109" - .250"

J hooks are used for supporting bail-type drop wire and deadend clamps from poles and crossarms.

• Used in drop cable installations as an attachment to strand for either accepting the bail of drop wire clamps, or for wrapping the support wire of drop cable.

• Clamp consists of a set of steel jaws, a 1/4" diameter “pig-tail” shaped bolt, and a hex nut.

• The jaws are rolled and stamped from AISI 1018 tempered steel.

• The bolt and hex nut are formed from Grade 2 Steel.

• Nut and bolt are hot dip galvanized to meet ASTM Specification A153, Class B3.

• Jaws are mechanically galvanized to meet ASTM Specification B695, Class 50, Type 1.
• Attaches to strand ranging in size from 1/4" (6.6m) to 7/16"(16m).

• Used in drop cable installations as an attachment to the strand for either accepting the bail of drop wire clamps, or for wrapping the support wire of drop cable.

• Consists of high strength Aluminum jaws, and a specially shaped bolt with square nut.

• Jaws are extruded from 6063-T6 aluminum.

• Bolt and nut are formed from Grade 2 steel.

• Bolt and nut are hot dip galvanized to meet ASTM Specification A153, Class B3.

• Bolt is 3/8" diameter for additional strength.

• Attaches to strand sizes ranging from 1/4" (6.6M) to 3/8" (10M).

• Used in drop cable installations as an attachment to figure 8 cable for accepting the bail of Drop Wire Clamps.

• Jaws are extruded and stamped from 5052 H-34 Aluminum.

• Clamp is comprised of a specially shaped bolt, two aluminum jaws, and a square nut.

• Bolt and nut are formed from Grade 2 Steel.

• Bolt and nut are hot dip galvanized to meet ASTM Specification A153, Class B3.

• Designed to secure CATV drop cable to the side of a subscriber's house by either accepting the bail of drop wire clamps, or by wrapping the support wire of drop cable around the screw eye.

• Manufactured from AISI 1016 Steel.

• P House Hooks are mechanically galvanized to meet ASTM Specification B695, Class 50, Type 1.

Used in drop cable installations as an attachment to the strand for accepting the bail of Drop Wire Clamps.Tensile strength of jaws and bolt exceeds 75,000 P.S.I.Clamping range is from 1/4"(6.6M) to 7/16"(16M).Clamp is comprised of a pigtail bolt, two jaws, and a square nut.Bolt and nut are formed from Grade 2 Steel.Jaws are rolled and stamped from 1018 tempered Steel.Bolt and nut are hot dip galvanized to meet ASTM Specification A153.Jaws are mechanically galvanized to meet ASTM Specification B695.

• Used for supporting wire on building walls or poles.
• Comprised of two parts, a steel pin and a U shaped ring.

• Used for supporting wire on building walls or poles.
• Comprised of two parts, a steel pin and a U shaped ring.

• Used for supporting wire on building walls or poles.
• Comprised of two parts, a steel pin and a U shaped ring.

• Used for supporting wire on building walls or poles.
• Comprised of two parts, a steel pin and a U shaped ring.

E Drop wire clamp with ribs. Used to secure telephone and CATV drop wire to wood or masonry.

Sold in bags of 50.

Banded service drop, maximum service load 1000lb.

The hook bolt guard arm bolts though the side of a wood crossarm for deadending telephone services and drops. Use with J1086 round washer.

• Constructed of high quality steel, hot-dip galvanized
• 1-3/8" DIA. 9/16 HOLE
• can be used with J8245 drop hook for wood crossarms

• 1000 PER CARTON


Used for mid-span drop wire take-offs in one or more directions for either lashed or self-supported cable

Will hold cable away from obstacles in the line of aerial construction

Designed for use with "p" type or Wirevise drop hardware

h-5577

MAST CLAMP WIRE HOLDERS Holds incoming service entrance cables Material: Porcelain Wire Holder, Adjustable Galvanized Steel Clamp. Madison P-18 1-1/4" -3 Mast Clamp Wire Holder, Porcelain Wire Holder WAL 610.

• Specially shaped hook for attaching drop wire clamps or drop wires to houses
• Constructed of high quality steel, mechanically plated
Rams Horn Drop Wire Hook H-5519

The minimum holding strength is 90% of the rated breaking strength of the support wire. Used to splice the support wire of Figure 8 Drop Cable.

• Wire Range: .062 - .100
• Used to splice galvanized steel messenger mid-span of a service drop
• Rated to hold a minimum of 90% of RBS of wire specified
• Designed to support both ends of self-supporting multi-pair drop wire that uses a solid galvanized steel messenger wire that is integrated into the jacket in a figure-8 configuration
•
  Allied Bolt - PART# AB505700


Aerial Eliptical Fiber Optic Drop Wire Clamp SI-0972

J hooks are used for supporting bail-type drop wire and deadend clamps from poles and crossarms.

The PLP FIBERLIGN® Tangent Support (FTS) offers another method of supporting ADSS Drop Cables with excellent unbalance load capability and bend relief support. This product is designed to connect directly to J-hooks for a economical alternative. One FTS can reduce pole clutter by replacing two Dead-end and j-hook connections.

ADSS Drop Cable Dead-end & ADSS Midspan Drop for FTTP .371 - .380 .94-.96YEL 26 (660)W/THIMBLE DROP CABLE DE ADSS 288811353 .371 - .380 9.4 - 9.6 Yellow 26
FIBERLIGN® ADSS Drop Cable Dead-end is able to secure the soft pliable surface of a drop cable without causing attenuation. Unlike wedge type Dead-ends, the formed wire Dead-end effectively transfers the axial load on the cable at the end of the Dead-end legs to a low uniform radial compression near the dead end loop. This transition of force is distributed over the length of the product thus allowing secure holding capability with minimized pressure on the cable or messenger.

PLP PREFORMED LINE PRODUCTS GRIP; DEADEND OPEN WIRE .109" GDE-2501 Color Code Black

• Helical shape insures low distribution of holding stresses and prevents premature fatigue breakage
• False or Double Dead-ending can be accomplished without cutting the wire
• GDE-2501 Galvanized Steel .109" Cable Diameter
• Color Code Black

PLP PREFORMED LINE PRODUCTS GRIP; DEADEND OPEN WIRE .120" GDE-2502 Color Code Green

• Helical shape insures low distribution of holding stresses and prevents premature fatigue breakage
• False or Double Dead-ending can be accomplished without cutting the wire
• GDE-2502 Galvanized Steel .120" Cable Diameter
• Color Code GREEN

PLP PREFORMED LINE PRODUCTS GRIP; DEADEND OPEN WIRE .063" DE-2505 Color Code Black

• Helical shape insures low distribution of holding stresses and prevents premature fatigue breakage
• False or Double Dead-ending can be accomplished without cutting the wire
• DE-2505 Galvanized Steel .063" Cable Diameter
• Color Code Black

PLP PREFORMED LINE PRODUCTS GRIP; DEADEND OPEN WIRE .083" DE-2506 Color Code Yellow

There is no quicker, easier way to attach Figure-8 drop wire or cable than with PREFORMED Dead-ends for Figure-8 RG-59/U coaxial cable messenger

• Helical shape insures low distribution of holding stresses and prevents premature fatigue breakage
• False or Double Dead-ending can be accomplished without cutting the wire
• DE-2506 Galvanized Steel .083" Cable Diameter
• Color Code YELLOW

The PLP FIBERLIGN® Tangent Support (FTS) offers another method of supporting ADSS Drop Cables with excellent unbalance load capability and bend relief support. This product is designed to connect directly to J-hooks for a economical alternative. One FTS can reduce pole clutter by replacing two Dead-end and j-hook connections.

FIBERLIGN Figure 8 Drop Cable Dead-End offers high-strength in a lightweight package. Simple to install, the dead-end is applied on the messenger component of the Figure 8 cable after separating the fiber component at the web.

CROUSE HINDS 2 INCH SERVICE ENTRANCE HEAD CLAMP. CRHEHC6 2" WEATHERHEAD

Crouse-Hinds 4-Hole Entrance cap of trade size 2-inches, is perfect for EMT, rigid and IMC conduits. It features die-cast aluminum construction and clamp-on connection. Cap is UL listed and cUL certified. Gooseneck Goose Neck Service Entrance Masthead Mast Head

CROUSE HINDS 1.5 INCH SERVICE ENTRANCE HEAD CLAMP. CRHEHC6 1.5" WEATHERHEAD

Crouse-Hinds 4-Hole Entrance cap of trade size 1.5-inches, is perfect for EMT, rigid and IMC conduits. It features die-cast aluminum construction and clamp-on connection. Cap is UL listed and cUL certified. Gooseneck Goose Neck Service Entrance Masthead Mast Head
