Communication Arm 3 & 2 Position Steel Under-build, 15° Angled WSO WB2751-B-HDG

HDG Communication Arm 3 & 2 - Position Steel Under-build, 15° Angled
15 degree angled Communication Arm 3 & 2 position Steel Under-build, galvanized for weather protection, and designed to allow for the addition of under-build cables. 36" & 24" in length from pole and 12" between mount holes.
All pole mounting and cable mounting holes are 11/16'' diameter.
WSO WB2751-B-HDG

Fiberglass Equipment Mount 15° 24" Mount Aluma-Form F1CA-MV-A24-F2

Single Phase/Cable Support 15 Degree Mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153 Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection. Rod Diameter - 1 1/2" length - 24"
Two bands and buckles required for banded installation. Not included.

Fiberglass Equipment Mount 15° 36" Mount Aluma-Form F1CA-MV-A36-F2

Single Phase/Cable Support 15 Degree Mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153 Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection. Rod Diameter - 1 1/2" length - 36" Two buckles required for all banded brackets and attachments.

Fiberglass Equipment/Standoff Mount 0° 12" Aluma-Form F1CA-MV-H12-F2

Single Phase/Cable Support 0 Degree Mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153. Includes 5/8" x2" bolt, lock washer with nut. Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection. Rod Diameter 1 - 1/2 Length 12" Weight - 6.3LBS
Two buckles required for all band brackets and attachments.

Fiberglass Equipment/Standoff Mount 0° 18" Aluma-Form F1CA-MV-H18-C7

Single Phase/Clover Leaf 7-Hole 18" 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A153 (6" to 8"" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band Banding system.
Two buckles required for all band brackets and attachments.

Fiberglass Equipment/Standoff Mount 0° 18" Aluma-Form F1CA-MV-H18-F2

Single Phase/Cable Support 0degree mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153. Includes 5/8" x2" bolt, lock washer with nut. Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection. Rod Diameter 1 - 1/2 Length 18" Weight - 7LBS
Two buckles required for all band brackets and attachments.

Fiberglass Equipment/Standoff Mount 15 Degree 30" Mount Aluma-Form F1CA-MV-A30-F2

Single Phase/Cable Support 15 Degree Mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153 Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection. Rod Diameter - 1 1/2" Two buckles required for all banded brackets and attachments.

Fiberglass Equipment/Standoff Mount 15° 12" Aluma-Form F1CA-MV-A12-F2

Single Phase/Cable Support 15 Degree Mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153 Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection. Rod Diameter - 1 1/2" length - 12"
Two buckles required for all band brackets and attachments.

Fiberglass Equipment/Standoff Mount 15° 18" Aluma-Form F1CA-MV-A18-C7

Clover Leaf 7-Hole Cable Support 15 Degree Mount Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153 Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection.
Two buckles required for all band brackets and attachments.

Fiberglass Equipment/Standoff Mount 15° 18" Aluma-Form F1CA-MV-A18-F2

18" Single Phase/Cable Support 15 Degree Mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153 Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection. Rod Diameter - 1 1/2" length - 18"
Two buckles required for all band brackets and attachment.

Fiberglass Equipment/Standoff Mount 15° 24" Mount Aluma-Form F1CA-MV-A24-BF2

Single Phase/Cable Support 15 Degree Mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153 Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection. Rod Diameter - 1 1/2" length - 24"
Two buckles required for all band brackets and attachments.

Fiberglass Equipment/Standoff Mount 15° 30" Mount Aluma-Form F1CA-MV-A30-BF2

Single Phase/Cable Support 15 Degree Mount 65-45-12 Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153 Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection. Rod Diameter - 1 1/2" Length Two buckles required for all banded brackets and attachments.

Fiberglass Single Phase/Clover Leaf 7-Hole 15° Mount 1.5"X12" Aluma-Form F1CA-MV-A12-C7

Clover Leaf 7-Hole Cable Support 15 Degree Mount Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-12 Ductile Iron, Hot dipped galvanized per ASTM A153 Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection.
Standoff Length: 12" Two buckles required for all banded brackets and attachments.
Workload:
P1(lbs) 1,800
P2(lbs) 1,400
P3(lbs) 10,000

Fiberglass Single Phase/Clover Leaf 7-Hole 15° Mount 1.5"X18" Aluma-Form F1CA-MV-A18-C7H

Clover Leaf 7-Hole Cable Support 15 Degree Mount Ductile Iron, Hot-dipped galvanized per ASTM A!53 (6" to 8" mounting centers) Accepts 5/8" pole mounting hardware. Can be banded using the Aluma-Form Bolt-A-Band banding system. End Fitting 65-45-18 Ductile Iron, Hot dipped galvanized per ASTM A153 Fiberglass Rod 1-1/2" diameter Super Smooth, proprietary veiled polyester rod with added ultraviolet protection.
Standoff Length: 18" Two buckles required for all banded brackets and attachments.
Workload:
P!(lbs) 1,200
P2(lbs) 900
P3(lbs) 10,000

Fiberglass STANDOFF BRACKET 0° - 36" Single Phase Double Position Bracket H-G1MA0136DDB

Fiberglass STANDOFF BRACKET 0° - 36" Single Phase Double Position Bracket H-G1MA0136ADB

36" SINGLE PHASE, DUAL POSITION 0 DEGREE STANDOFF BRACKET, ALUMINUM END FITTING, ALUMINUM BASE.
ACCEPTS 5/8 MOUNTING HARDWARE
ROD FIBERGLASS, MPS GRAY ULTRAVIOLET PROTECTIVE COATING.
