Alley arms, crossarms mounted to one side of the pole, require rigid bracing to insure proper alignment of power distribution and transmission lines. Sturdy angle steel alley arm braces mount at a 45-degree angle and come complete with a solidly welded lineman step. These braces are mounted to the side of the arm by a machine bolt and attached to the pole with two 1/2-inch lag screws.

Alley arms, crossarms mounted to one side of the pole, require rigid bracing to insure proper alignment of power distribution and transmission lines. Sturdy angle steel alley arm braces mount at a 45-degree angle and come complete with a solidly welded lineman step. These braces are mounted to the side of the arm by a machine bolt and attached to the pole with two 1/2-inch lag screws.

Alley arms, crossarms mounted to one side of the pole, require rigid bracing to insure proper alignment of power distribution and transmission lines. Sturdy angle steel alley arm braces mount at a 45-degree angle and come complete with a solidly welded lineman step. These braces are mounted to the side of the arm by a machine bolt and attached to the pole with two 1/2-inch lag screws.

29.5" LNG 1 3/4x1 3/4 X 3/16
Sold as pair right/left
HOT DIPPED GALVANIZED

Flat Crossarm Brace 30" long. Have rounded ends and are punched at one end with a 11/16" hole, with a 11/16" hole at the other end. Holes punched 1-inch from brace end to center of hole. Hot dip galvanized. (096359239482).

Braceless crossarm gains improve the stability of the crossarm and eliminate the need for crossarm braces and pole gaining.The design improves the structure appearance and permits the use of fiberglass, wood, steel channel or steel tubular arms. Accommodates pole diameters from 6 inches to 12 inches. Pole mounting slots are 13/16 inch wide on the top slot and 11/16 inch on bottom slot. Crossarm range: 4-1/4" - 6"

Crossarm Range: 3-1/2 - 8

Braceless crossarm gains improve the stability of the crossarm and eliminate the need for crossarm braces and pole gaining. The design improves the structure appearance and permits the use of fiberglass, wood, steel channel or steel tubular arms. Accommodates pole diameters from 6 inches to 12 inches. Pole mounting slots are 13/16 inch wide on the top slot and 11/16 inch on bottom slot. Arm mounting slots are 9/16 inch wide by1-1/2 inch .

Braceless crossarm gains improve the stability of the crossarm and eliminate the need for crossarm braces and pole gaining.The design improves the structure appearance and permits the use of fiberglass, wood, steel channel or steel tubular arms. Pole Mounting Slots 13/16 wide on top & 11/16 wide on Bottom Accommodates pole diameters from 6" - 12". Arm mounting slots are 9/16 inch wide by1-1/2 inch . Crossarm range: 4-1/2" - 6"

28" x 1/4" x 1 1/4" flat crossarm braces, used in pairs, are an inexpensive means of aligning and supporting crossarms. Mounting hole diameters are 7/16-inch for 3/8-inch crossarm mounting bolts and 9/16-inch for pole mounting with 1/2-inch lag screw or through bolt. Hole centers are 1-inch from the brace ends, which are rounded for extra safety.

H-J1512 Brace, Cross-arm, Span 72", Drop 22"
One piece, angle steel, double span braces are used to support heavy cross-arm construction. Braces are attached to the underside of the cross-arm with 1/2" bolts or lag screws and fastened to the pole with a 5/8" bolt. The pole mounting section is designed to allow more than ample clearance for wrenching.

One-piece V-type crossarm brace is fabricated from angle steel and provides heavy-duty support for crossarm stability.

• 75" length end-to-end
• 9/16" crossarm mouinting hole
• 11/16" pole mounting hole
• In compliance with ANSI C135.6 specification
• Galvanized per ASTM A-153

(42in length) These braces are used as tension members on the side of the arm opposite the odd conductor to compensate for the unbalanced load. Pole mounting end is flattened so the brace can be used as either a right-hand or left-hand member.

• HOT DIP GALVANIZED
• Rounded ends for safety
• Style A accommodates 3/8-inch and 1/2-inch lag screw or bolt
• Style B has offset ends to fit flat
• Style B accommodates 1/2-inch and 5/8-inch lag screw or bolt

Flat crossarm braces, used in pairs, are an inexpensive means of aligning and supporting crossarms. Mounting hole diameters are 7/16" for 3/8" crossarm mounting bolts and 9/16" for pole mounting with 1/2" lag screw or through bolt.  Hole centers are 1" from the brace ends, which are rounded for extra safety.

30" x 1/4" x 1 1/4" flat crossarm braces, used in pairs, are an inexpensive means of aligning and supporting crossarms. Mounting hole diameters are 7/16-inch for 3/8-inch crossarm mounting bolts and 9/16-inch for pole mounting with 1/2-inch lag screw or through bolt. Hole centers are 1-inch from the brace ends, which are rounded for extra safety. 30 inch Flat Cross-arm Brace

18" x 1/4" x 1 1/4" guard arm brace is used for light duty support and stability of crossarms in telecommunications construction. Mounts to the crossarm with a 3/8-inch diameter bolt and to the pole with a 1/2-inch diameter lag screw.

The insulator support angle mounts at the ends of a double arm and acts as a fastening point for suspension or pin-type insulators.

• HOT DIP GALVANIZED
• Manufactured from 2-1/2 x 2-1/2 x 1/4-inch steel angle
• All holes accommodate 5/8-inch bolts

Used to support the outer end of extension bolts when installing a parallel line to existing aerial plant.

• The distance between the Suspension Clamp and the above mounting hole is 8-3/4".
• Stock size is 1/8" x 1-3/8".

• Stamped from AISI 1018 steel.

• Hot dip galvanized to meet ASTM Specification B695.

Hughes 2045-CC30-9-11 Cross Arm Pair
Each brace pair has identical right and left hand components. Each nutted connection is tapped to make a double nut connection ensuring permanently tight hardware
Specifications:
Reversible Span: 60"
Drop: 18"
Wood Length: 29-1/2"
Fitting Angle: 30 degrees
Wood Cross Section: 1-5/8" X 2-1/4"
Hole Size: 9/16" at arm, 11/16" at pole
Material: Wood, Hot Dip Galvanized
Mounting: Underarm, Reversible
Number of Braces: Pair

ALU RA 6018 WOOD BRACE PAIR REVERSABLE
Aluma-Form braces feature end fittings of extruded aluminum 6061-T6 alloy that eliminates the need for bolted fittings. The greater shear and friction area gripped by the Aluma-Form end fitting allows the use of smaller wood members thereby reducing weight and producing a more eye pleasing brace that is stronger than bolted fittings.

34-31/32 HOLE to HOLE
9/16 HOLE IN ANGLED END
11/16 HOLE IN STRAIGHT END
WOOD IS 27-5/8 LONG 1-3/4 X 1-3/4

High Density APITONG BRACES Cross Section 1-3/4” x 1-3/4” Hole Size 9/16” at arm 11/16” at pole.
